NEC MultiSync FP1350 - Page 38

4-18
REMARK
SYMBOL
Connect the CN-SC1 to the CN-
SC2.
Clamp the wires.
CN-ASD
CN-AF
REMARK
SYMBOL
Clamp the ANODE LEAD with
the CLAMPER WIRE (H19.5).
119
Don’t change the from the LEAF,
SPRING.
169
CLAMPER,WIRE
(BACK SIDE)
CASE,SHIELDING (CRT,F)
CRT PWB
CN-SC1
CN-SC2
CN-ASD
CN-ZDY
CN-SD
CN-EMF
CN-EMF
CN-VSC
CN-HSC
CN-AF
clamp
SAFETY
Clamp
119
170
101
101
101
168
169
Y’
Y’
Y’
Y’
