NEC MultiSync FP1350 - Page 92

5-51
TIMING NAME 1 VGA350 2 VGA400 3 VGA480 4 640*400@70Hz 5 800*600@60
Pixel Clock
H.Frequency
V.Frequency
28.322[MHz]
31.469[kHz]
70.086[Hz]
28.322[MHz]
31.469[kHz]
70.087[Hz]
25.175[MHz]
31.469[kHz]
59.940[Hz]
25.175[MHz]
31.467[kHz]
70.086[Hz]
40.000[MHz]
37.879[kHz]
60.317[Hz]
H.Tortal Time
H.Addr Time
H.Blank Time
H.Front Porch
H.Sync Time
H.Back Porch
900 [dots]
720 [dots]
180 [dots]
18 [dots]
108 [dots]
54 [dots]
31.778 [us]
25.778 [us]
6.356 [us]
0.636 [us]
3.813 [us]
1.907 [us]
900 [dots]
720 [dots]
180 [dots]
18 [dots]
108 [dots]
54 [dots]
31.777 [us]
25.422 [us]
6.355 [us]
0.636 [us]
3.813 [us]
1.907 [us]
800 [dots]
640 [dots]
160 [dots]
16 [dots]
96 [dots]
48 [dots]
31.778 [us]
25.422 [us]
6.356 [us]
0.636 [us]
3.813 [us]
1.907 [us]
800 [dots]
640 [dots]
160 [dots]
17 [dots]
64 [dots]
79 [dots]
31.778 [us]
25.422 [us]
6.356 [us]
0.675 [us]
2.542 [us]
3.138 [us]
1056 [dots]
800 [dots]
256 [dots]
40 [dots]
128 [dots]
88 [dots]
26.400 [us]
20.000 [us]
6.400 [us]
1.000 [us]
3.200 [us]
2.200 [us]
V.Tortal Time
V.Addr Time
V.Blank Time
V.Front Porch
V.Sync Time
V.Back Porch
449 [lines]
350 [lines]
99 [lines]
37 [lines]
2 [lines]
60 [lines]
14.268 [ms]
11.122 [ms]
3.146 [ms]
1.176 [ms]
0.064 [ms]
1.907 [ms]
449 [lines]
400 [lines]
49 [lines]
12 [lines]
2 [lines]
35 [lines]
14.268 [ms]
12.711 [ms]
1.557 [ms]
0.381 [ms]
0.064 [ms]
1.112 [ms]
525 [lines]
480 [lines]
45 [lines]
10 [lines]
2 [lines]
33 [lines]
16.683 [ms]
15.253 [ms]
1.430 [ms]
0.318 [ms]
0.064 [ms]
1.049 [ms]
449 [lines]
400 [lines]
49 [lines]
13 [lines]
2 [lines]
34 [lines]
14.268 [ms]
12.711 [ms]
1.557 [ms]
0.413 [ms]
0.064 [ms]
1.080 [ms]
628 [lines]
600 [lines]
28 [lines]
1 [lines]
4 [lines]
23 [lines]
16.579 [ms]
15.840 [ms]
0.739 [ms]
0.026 [ms]
0.106 [ms]
0.607 [ms]
Scan Type
H.Sync Polarity
V.Sync Polarity
Non-interlaced
Positive
Negative
Non-interlaced
Negative
Positive
Non-interlaced
Negative
Negative
Non-interlaced
Negative
Negative
Non-interlaced
Positive
Positive
Separate
Separate Separate Separate Separate
TIMING NAME 6 MAC640*480 7 VESA640*350@85Hz 8 VESA640*400@85Hz 9 VESA640*480@75Hz 10 XGA
Pixel Clock
H.Frequency
V.Frequency
30.240[MHz]
35.000[kHz]
66.667[Hz]
31.500[MHz]
37.861[kHz]
85.080[Hz]
31.500[MHz]
37.861[kHz]
85.080[Hz]
31.500[MHz]
37.500[kHz]
75.000[Hz]
44.900[MHz]
35.522[kHz]
87.064[Hz]
H.Tortal Time
H.Addr Time
H.Blank Time
H.Front Porch
H.Sync Time
H.Back Porch
864 [dots]
640 [dots]
224 [dots]
64 [dots]
64 [dots]
96 [dots]
28.571 [us]
21.164 [us]
7.407 [us]
2.116 [us]
2.116 [us]
3.175 [us]
832 [dots]
640 [dots]
192 [dots]
32 [dots]
64 [dots]
96 [dots]
26.413 [us]
20.317 [us]
6.095 [us]
1.016 [us]
2.032 [us]
3.048 [us]
832 [dots]
640 [dots]
192 [dots]
32 [dots]
64 [dots]
96 [dots]
26.413 [us]
20.317 [us]
6.095 [us]
1.016 [us]
2.032 [us]
3.048 [us]
840 [dots]
640 [dots]
200 [dots]
16 [dots]
64 [dots]
120 [dots]
26.667 [us]
20.317 [us]
6.349 [us]
0.508 [us]
2.032 [us]
3.810 [us]
1264 [dots]
1024 [dots]
240 [dots]
8 [dots]
176 [dots]
56 [dots]
29.577 [us]
22.806 [us]
6.771 [us]
0.535 [us]
3.029 [us]
3.207 [us]
V.Tortal Time
V.Addr Time
V.Blank Time
V.Front Porch
V.Sync Time
V.Back Porch
525 [lines]
480 [lines]
45 [lines]
3 [lines]
3 [lines]
39 [lines]
15.000 [ms]
13.714 [ms]
1.286 [ms]
0.086 [ms]
0.086 [ms]
1.114 [ms]
445 [lines]
350 [lines]
95 [lines]
32 [lines]
3 [lines]
60 [lines]
11.754 [ms]
9.244 [ms]
2.509 [ms]
0.845 [ms]
0.079 [ms]
1.585 [ms]
445 [lines]
400 [lines]
45 [lines]
1 [lines]
3 [lines]
41 [lines]
11.754 [ms]
10.565 [ms]
1.189 [ms]
0.026 [ms]
0.079 [ms]
1.083 [ms]
500 [lines]
480 [lines]
20 [lines]
1 [lines]
3 [lines]
16 [lines]
13.333 [ms]
12.800 [ms]
0.533 [ms]
0.027 [ms]
0.080 [ms]
0.427 [ms]
408 [lines]
384 [lines]
24 [lines]
0 [lines]
4 [lines]
20 [lines]
23.839 [ms]
22.715 [ms]
1.124 [ms]
0.089 [ms]
0.177 [ms]
0.858 [ms]
Scan Type
H.Sync Polarity
V.Sync Polarity
Non-interlaced
Negative
Negative
Non-interlaced
Positive
Negative
Non-interlaced
Negative
Positive
Non-interlaced
Negative
Negative
Interlaced
Positive
Positive
Composite + Sync On G Separate Separate Separate Separate
Adjustment Signal (1)
