NEC MultiSync FP1350 - Page 94

5-53
TIMING NAME 21 VESA1280*1024@75Hz 22 VESA1600*1200@75Hz 23 VESA1600*1200@85Hz 24 VESA1920*1440@75Hz 25 H.HOLD1
Pixel Clock
H.Frequency
V.Frequency
135.000[MHz]
79.976[kHz]
75.025[Hz]
202.500[MHz]
93.750[kHz]
75.000[Hz]
229.500[MHz]
106.250[kHz]
85.000[Hz]
297.000[MHz]
112.500[kHz]
75.000[Hz]
27.900[MHz]
31.000[kHz]
54.963[Hz]
H.Tortal Time
H.Addr Time
H.Blank Time
H.Front Porch
H.Sync Time
H.Back Porch
1688 [dots]
1280 [dots]
408 [dots]
16 [dots]
144 [dots]
248 [dots]
12.504 [us]
9.481 [us]
3.022 [us]
0.119 [us]
1.067 [us]
1.837 [us]
2160 [dots]
1600 [dots]
560 [dots]
64 [dots]
192 [dots]
304 [dots]
10.667 [us]
7.901 [us]
2.765 [us]
0.316 [us]
0.948 [us]
1.501 [us]
2160 [dots]
1600 [dots]
560 [dots]
64 [dots]
192 [dots]
304 [dots]
9.412 [us]
6.972 [us]
2.440 [us]
0.279 [us]
0.837 [us]
1.325 [us]
2640 [dots]
1920 [dots]
720 [dots]
144 [dots]
224 [dots]
352 [dots]
8.889 [us]
6.465 [us]
2.424 [us]
0.485 [us]
0.754 [us]
1.185 [us]
900 [dots]
720 [dots]
180 [dots]
18 [dots]
108 [dots]
54 [dots]
32.260 [us]
25.810 [us]
6.450 [us]
0.640 [us]
3.870 [us]
1.940 [us]
V.Tortal Time
V.Addr Time
V.Blank Time
V.Front Porch
V.Sync Time
V.Back Porch
1066 [lines]
1024 [lines]
42 [lines]
1 [lines]
3 [lines]
38 [lines]
13.329 [ms]
12.804 [ms]
0.525 [ms]
0.013 [ms]
0.038 [ms]
0.475 [ms]
1250 [lines]
1200 [lines]
50 [lines]
1 [lines]
3 [lines]
46 [lines]
13.333 [ms]
12.800 [ms]
0.533 [ms]
0.011 [ms]
0.032 [ms]
0.491 [ms]
1250 [lines]
1200 [lines]
50 [lines]
1 [lines]
3 [lines]
46 [lines]
11.765 [ms]
11.294 [ms]
0.471 [ms]
0.009 [ms]
0.028 [ms]
0.433 [ms]
1500 [lines]
1440 [lines]
60 [lines]
1 [lines]
3 [lines]
56 [lines]
13.333 [ms]
12.800 [ms]
0.533 [ms]
0.009 [ms]
0.027 [ms]
0.498 [ms]
564 [lines]
428 [lines]
136 [lines]
52 [lines]
2 [lines]
82 [lines]
18.194 [ms]
13.807 [ms]
4.387 [ms]
1.677 [ms]
0.065 [ms]
2.645 [ms]
Scan Type
H.Sync Polarity
V.Sync Polarity
Non-interlaced
Positive
Positive
Non-interlaced
Positive
Positive
Non-interlaced
Positive
Positive
Non-interlaced
Negative
Positive
Non-interlaced
Positive
Positive
Separate
Separate Separate Separate Composit
TIMING NAME 26 H.HOLD2(110K) 27 H.HOLD2(115K) 28 V.MAX 29 V.RASTER 30 EDID
Pixel Clock
H.Frequency
V.Frequency
237.600[MHz]
110.000[kHz]
160.000[Hz]
142.140[MHz]
115.000[kHz]
160.000[Hz]
84.500[MHz]
65.000[kHz]
80.65[Hz]
78.750[MHz]
60.023[kHz]
75.029[Hz]
28.322[MHz]
31.463[kHz]
42.01[Hz]
H.Tortal Time
H.Addr Time
H.Blank Time
H.Front Porch
H.Sync Time
H.Back Porch
2160 [dots]
1600 [dots]
560 [dots]
64 [dots]
192 [dots]
309 [dots]
9.091 [us]
6.734 [us]
2.357 [us]
0.269 [us]
0.808 [us]
1.280 [us]
1236 [dots]
900 [dots]
336 [dots]
68 [dots]
100 [dots]
168 [dots]
8.695 [us]
6.332 [us]
2.364 [us]
0.478 [us]
0.704 [us]
1.182 [us]
1300 [dots]
1024 [dots]
276 [dots]
24 [dots]
92 [dots]
160 [dots]
15.38 [us]
12.12 [us]
3.26 [us]
0.28 [us]
1.09 [us]
1.89 [us]
1328 [dots]
1024 [dots]
288 [dots]
16 [dots]
96 [dots]
176 [dots]
16.66 [us]
13.003 [us]
33.657 [us]
0.203 [us]
1.219 [us]
2.235 [us]
900 [dots]
720 [dots]
180 [dots]
18 [dots]
108 [dots]
54 [dots]
31.777 [us]
25.422 [us]
6.36 [us]
0.636 [us]
3.813 [us]
1.907 [us]
V.Tortal Time
V.Addr Time
V.Blank Time
V.Front Porch
V.Sync Time
V.Back Porch
687 [lines]
660 [lines]
27 [lines]
1 [lines]
4 [lines]
22 [lines]
6.250 [ms]
6.000 [ms]
0.250 [ms]
0.013 [ms]
0.038 [ms]
0.200 [ms]
718 [lines]
690 [lines]
28 [lines]
1 [lines]
4 [lines]
23 [lines]
6.250 [ms]
6.000 [ms]
0.250 [ms]
0.013 [ms]
0.038 [ms]
0.200 [ms]
806 [lines]
596 [lines]
210 [lines]
89 [lines]
6 [lines]
115 [lines]
12.4 [ms]
9.169 [ms]
3.231 [ms]
1.343 [ms]
0.092 [ms]
1.796 [ms]
800 [lines]
788 [lines]
13 [lines]
0 [lines]
3 [lines]
9 [lines]
13.328 [ms]
13.128 [ms]
0.217 [ms]
0 [ms]
0.05 [ms]
0.150 [ms]
749 [lines]
685 [lines]
64 [lines]
14 [lines]
3 [lines]
47 [lines]
23.8 [ms]
21.767 [ms]
2.034 [ms]
0.445 [ms]
0.095 [ms]
1.494 [ms]
Scan Type
H.Sync Polarity
V.Sync Polarity
Non-interlaced
Positive
Positive
Non-interlaced
Positive
Positive
Non-interlaced
Negative
Negative
Non-interlaced
Positive
Positive
Non-interlaced
Negative
Negative
Separate Separate Separate Separate Separate
Adjustment Signal (3)
