NDA-24299 CHAPTER 5
Page 103
Revision 1.0
DATA PROGRAMMING
Assignment of FCH Related Data
STEP 9: ADPCL
Assign the destination PC (Point Code) on speech channel route (Logical Route) basis.
LGRT=1 PC=3
STEP 10: ACSCL
Assign the CSC Group Number (CSCG) for designating the Dch and the location of the CCH, in
cooperation with the FPC of the node that is connected to CCIS link.
STEP 11: ACIC1
Assign the data to establish the relation between Point Code of the destination node and CSCG (CSC
Group) of the Basic Route.
Enter the Destination PC assigned by the ADPCL command, and CSCG number of the Basic Route
(even number) assigned by the ACSCL command. It is not necessary to assign the CSC group number
of the Alternate Route here.
PC=3 CSCG=2
7.5 FCCS Link via Internet/Intranet
The system can exchange the FCCS data via the Internet/Intranet. As shown below, an FCCS Link can be
established by using the following features:
• External Router
• Fusion over IP
7.5.1 External Router
This feature allows the system to exchange the FCCS data via the Internet/Ethernet. For this feature, an
FCCS link is connected to an external router.
CSCG
2-254(n)
CICG FPC
LENS of CCH
MG U G
2
(Basic/
Primary
Route)
0200020
1200020
2200020
3200020
4200020
5200020
6200020
7200020
CSCG
2-255(n+1)
CICG FPC
LENS of CCH
MG U G
3
(Alternate
Route)
0 200020
1 200020
2 200020
3 200020
4 200020
5 200020
6 200020
7 200020
To Next Page
