CHAPTER 5 NDA-24299
Page 104
Revision 1.0
DATA PROGRAMMING
Assignment of FCH Related Data
Figure 5-45 External Router - Overview
Figure 5-46 Hardware Connections for External Router
Internet/
Intranet
FCCS link
Speech Data for Fusion
Router
Router
Node A
Node B
Signaling data
DTI DTI
Fusion
Network
FCCS signaling is exchanged via the Internet/Intranet.
HUB
Speech
ROUTER
signaling
CPU
PBX
FCH
FCH
FGH
DTI
HUB
LANI
10BASE-T
ACRD
ACTK
AFCH
AFPC
ACRD
ACTK
AGIP
AETH
DTI: Digital Trunk Interface
FCH: Fusion Control Handler (PA-FCHA)
FGH: Fusion Gateway Handler (PA-FCHA)
LANI: LAN Interface (PZ-PC19)
POWER
<Procedure>
1. Nailed-down Connection between FCH and FGH ca
2. Connect two LANI cards and HUB cards, respective
(slot 00/03)
Fusion
Network
Internet/
Intranet
Note: This FCH card is optional use.
Note
Nailed-down
Connection
AFCD
