NDA-24299 CHAPTER 5
Page 75
Revision 1.0
DATA PROGRAMMING
Assignment of Telephone Numbers
6.1 Assignment of Connection Route/Trunk Data
STEP 1: ACRD
Using the ACRD command, assign the connection route data of Fusion link. The data must be
assigned for both B-channel and D-channel. Assign appropriate data referring to Table 5-1.
Figure 5-21 shows an example of route numbers for B-ch and D-ch.
Figure 5-21 B-ch and D-ch (Example)
The ACRD command display should look similar to Figure 5-22.
Figure 5-22 ACRD Command Display (Example)
N
E
C
N
E
A
X
2
4
0
0
I
M
S
Fusion Network
D ch
D ch
B ch
B ch
B-ch: Bearer Channel D-ch: Data Channel FPC: Fusion Point Code
Route 10
Route 11
Route 12
Route 13
:
:
:
:
Node A
FPC = 1
N
E
C
N
E
A
X
2
4
0
0
I
M
S
Node B
FPC = 2
C_RT
For Help, press F1
10
CDN CDN CDNFUNC FUNC FUNCDT DT DT
1
TF
2
3
4
5
6
7
8
9
10
11
12
13
TCL
RLP
SMDR
LSG
PAD
TRKS
TC/EC
FPEG
TC
MTC
STSEQ
LKIND
IPLYR
FINT
3
4
2
0
12
7
0
0
0
14
15
16
17
FGH
MMN
0
0
0
0
0
0
0
0
ACRD (Assignment of Connection Route Class Data)
This figure shows an example of data setting for a B-ch route.
C_RT: 1-1023
