CHAPTER 7 NDA-24299

Page 182

Revision 1.0

TROUBLESHOOTING

23-W FCH Alternate Routing Start Notification

10. 23-W FCH Alternate Routing Start Notification

Figure 7-24 illustrates the message that is displayed when the indicated FCH card of self-Node becomes

inoperative. This message is also displayed when the card is placed in make-busy status by MNT 3 switch

operation or when the FCH of the adjacent node becomes inoperative.

Figure 7-24 23-W FCCH Alternate Routing Start Notification

11. 23-X FCH Alternate Routing End Notification

Figure 7-25 illustrates the message that is displayed when an inoperative FCH card of self-Node resumes its

operation. Therefore, when the card is placed in make-idle status by MNT 3 switch operation, this message is

also displayed.

Figure 7-25 23-X FCCH Alternate Routing End Notification

1. xx0x 0000 0000 0000 2. 0000 0000 0000 0000 3. 0000 .........

FCH Mounting Location

MG: Module Group

U: Unit (0-3)

G: Group (00-23)

FCH CKT No.

Circuit Number of FCH (0 - 7)

b0b7
