CHAPTER 7 NDA-24299
Page 174
Revision 1.0
TROUBLESHOOTING
23-U FCH Status Information
Figure 7-15 23-T FCCH Fault Recovery Notification (Continued)
9. 23-U FCH Status Information
Figure 7-16 illustrates the general format of the message that is displayed when the status change of FCH (PA-
FCHA) card is detected, which includes “FCH Initial Setting Failure,” “ETHER Transfer Failure.” When this
message is displayed, follow the procedure explained on a fault information basis.
1. xx0x xxxx xxxx xxxx
2. xxxx xxxx xxxx 0000 ......
LTINF=03H is indicated;
2 Bytes
Recovery Port No. (Source)
4 Bytes
IP Address of the destination FGH/Router
on which connection failure recovered.
Connection Operating Type
01=Client
02=Server
Kind of Port
01=Port for FCCS Signaling
02=Port for Bch Controlling
2 Bytes
Recovery Port No. (Destination)
Recovery Side Information
01=Not determined
02=Source side
03=Destination side
}
}
}
Note :Refer to the previous page for this information.
Note
To Next Page
