3. Convenient Features
39
Pincushion
By this feature, it enables to adjust left and right side or top and bottom side independently for
reforming pincushion distortion.
1. Press the ▼ button with no menu displayed.
The [KEYSTONE] screen will be displayed.
• Press the KEYSTONE button when using
the remote control.
2. Press the ▼ or ▲ button to select [PINCUSH-
ION LEFT/RIGHT] or [PINCUSHION TOP/
BOTTOM].
3. Press the ◀ or ▶ button to correct distor-
tion.
NOTE:
• The [PINCUSHION LEFT/RIGHT] or [PINCUSHION TOP/BOT-
TOM] item is not available when [KEYSTONE HORIZONTAL],
[KEYSTONE VERTICAL] or [CORNERSTONE] is activated.
• Before performing correction, set the lens shift to the
center position.
4. Press the EXIT when [PINCUSHION] adjust-
ment is completed.
NOTE:
• Even when the projector is turned on, the last used correction values are applied.
• [PINCUSHION] and [CORNERSTONE] corrections can cause the image to be slightly blurred because the correction is made electroni-
cally.
