4. Using On-Screen Menu
63
CORNERSTONE Fits a projected image within the border of the screen easily by align
the four corner of an image to the ones of the screen. (→ page 37)
RESET Returns all the above items to the factory preset values.
TIP:
• Adjustable range of the KEYSTONE and the CORNERSTONE:
Horizontal Direction Vertical Direction
Approx. ±30° (Max) Approx. ±30° (Max)
Adjustable range may be narrower depending on input signal.
Simultaneous display of 2 images [PIP]
Two images are projected by a single projector.
SUB INPUT Select the input signal to be displayed in the sub-display.
Please refer to “3-7 Displaying Two Pictures at the Same Time” (→ page 44) for details on the
operation.
SUB INPUT POSITION Select the display position of the sub-screen from 4 locations.
(BOTTOM-LEFT) (BOTTOM-RIGHT)
(TOP-LEFT) (TOP-RIGHT)
Sub-display
Main display
PICTURE SWAP The videos in the main display and sub-display will be switched.
When turned “OFF” When turned “ON”
Sub-display video
Main display
video
Sub-display
video
Main display video
NOTE:
• When the input terminal of the main display is set to LAN, the display position cannot be switched.
To Next Page
