Necchi C360 - Attaching the Straight Stitch Needle Plate

17
Attaching the straight stitch needle plate
n
Attention
- Turn the power switch to off ("O").
- Only specic stitches are applicable
while using straight stitch needle plate,
including the Direct Pattern Group
number 1 and 3, Regular Pattern Group
number 000 and Quilting Pattern Group
number 047.
1
3 000
047
The particular design of smaller central hole
can give a better support of the fabric during
straight stitch sewing.
Thus, the fabric can be prevented from being
pulled down into bobbin/hook area, especially
in the beginning or end of a seam.
Remove the needle, presser foot and presser
foot holder.
Use the L-screwdriver to unscrew and remove
the regular needle plate.
①
Screws
Change to straight stitch needle plate and
tighten the screws.
1
1
