Necta Snakky Max - Wiring Diagram Legend

© by NECTA VENDING SOLUTIONS SpA 0110 239-00
58
INITIALS DESCRIPTION
WIRING DIAGRAM LEGEND
INITIALS DESCRIPTION
CCB CAN BUS CONNECTOR
CF FILTER CONDENSER
CM0-9 VENDING MOTOR CAM
CMV DISPENSING COMPARTMENT MOTOR CAM
D DIODE
EX CONNECTOR FOR EXECUTIVE COIN MECH
FA RADIO INTERFERENCE SUPPRESSOR
FD PHOTODIODE
FT PHOTOTRANSISTOR
IP DOOR SWITCH
ISA OPEN HATCH SWITCH
LCD LIQUID CRYSTAL DISPLAY
M1-... RELEASE MOTOR
MBV DISPENSING COMPARTMENT LOCK MOTOR
MDB CONNECTOR FOR MDB COIN MECH
MIP PROGRAMMING ACCESS MICROSWITCH
MS1 HATCH MOTOR MICROSWITCH
MUR COMPRESSOR
MVT FAN
NTC1-. TEMPERATURE PROBE
PIP PROGRAMMING ACCESS BUTTON
R ANTI-CONDENSATION HEATING ELEMENT
RS232 SERIAL PORT
RT BALLAST
SALIM SUPPLY UNIT LED BOARD
SLED LED BOARD
SOR OUT/R BOARD
SP PUSH-BUTTON BOARD
ST STARTER
SUC C.P.U. BOARD
TR TRANSFORMER
TX.... DELAYED FUSE (X=COURRENT)
