Factory Set Preset Weld Settings (Drawn Arc)
Preset
Bank 1
Nelson Stud
Type
Stud Size

Current
(Amps)
Time
(ms)
1
IS‐Studs
3
200
150
2
IS‐Studs
4
280
200
3
IS‐Studs
5
350
230
4
SD6, MR M8, S6
6
410
250
5
MP (F) M8
7
470
300
6
MR M10, S8
8
550
300
7
MP (F) M10
9
650
300
8
SD10, MR M12,
S10
10
750
350
Estimated values for the parameters for the Drawn Arc Procedure
1
:
• I[A]  80 x  [mm]
• t[ms]  20 x  mm]
Prest bank 0 or 1 are loaded (such that presets 0‐8 are as described above)
when in drawn arc mode.
Note!
The preset bank may be selected manually using Function Code
F44.
1. This estimated values are taken from the standard DIN EN ISO 14555: ʺArc
welding of metallic materialsʺ (2006). The estimated values must be adjusted to
the concrete conditions (cable length, surface condition and welding position).
☞
