Stud welding unit N800i
As of 24.08.2021
Manual part number: BE 1221
82
Tucker GmbH, Mail / Post: Max-Eyth-Str.1, 35394 Gießen, Germany
F
code
Description
Possible Values
Default
Unit
Notes
F33
Disable Welding on
Weld Error
OFF ON
OFF
X
Turn this on to disable welding when a weld is out of specified weld
energy/ drop range. Flashes ‘WELD ERROR!’ and requires a password
to continue. Password is 123456 by default, but can be changed to any
number up to 9 di- gits. Use lock mode 2 or 3 to set this password.
F34
Drop Time Tolerance
0 to 1000
100
Ms
This defines the tolerance allowed from target weld drop time for deter-
mining good/bad weld.
F35
Weld Energy
Tolerance
1 to 20
10
%
This defines the tolerance allowed from target weld drop time for deter-
mining good/bad weld.
F36
Process Monitor
Error code on failed
weld
OFF ON
OFF
X
When enabled, an error code is given when the weld is out of tolerance.
F37
Pulse Cleaning
Enable
OFF ON
OFF
X
When enabled, the weld current will pulse high current and low current
be- fore the weld.
F38
Pulse Cleaning
Threshold Voltage
0.00 to 50.00
30.00
V
Threshold voltage to stop pulsing and begin the main weld. When
voltage is above this value, it terminates pulsing and starts the weld.
F39
Pulse Cleaning
Maximum Pulses
1 to 10
4
X
Maximum number of pulses before starting main weld.
