Stud welding unit N800i
As of 24.08.2021
Manual part number: BE 1221
Tucker GmbH, Mail / Post: Max-Eyth-Str.1, 35394 Gießen, Germany
This is a drop time measurement func- tion THAT DOES AN ACTUAL
WELD. If F48 (Drop Time Configurati- on) is in either Manual or Auto
mode, the measurement taken during the weld (while viewing this
function) will be stored in this function and used in weld timing. The
measured value may be overridden by using the arrow keys. This value
changes to 7ms when short cycle mode is enabled, 12ms when disabled.
This value changes automati- cally depending on F30 (short cycle mode)
and the gun interface installed in the unit.
I= Current
(Amps)
V= Voltage
(Volts)
tM= Main current
time
(ms)
E= Energy
(Joules)
tD= Drop Time
(ms)
tP= Pilot Time
(ms)
Pass/Fail indicator
Cable Resistance
(mΩ)
This F code gives information about the last weld. To save these weld re-
sults as the target (for weld compari- son), press and hold the ‘Lock’ key.
To clear targets, exit to time\current mode and click the ’Lock’ key +
desired pre- set key at the same time. For the main preset (no preset),
use the ’Lock’ key + timedown key
