Tucker GmbH, Mail / Post: Max-Eyth-Str.1, 35394 Gießen, Germany
Stud welding unit N800i
As of 24.08.2021
Manual part number: BE 1227
For automated systems, select the ap- propriate fieldbus selection to
deter- mine the IO map and sequence of signals. For standard mode,
disable this F code.
For automated systems, this output signal is given after each weld to
indicate that the weld was successful. The Signal is 24VDC
(unregulated), active high, 500ms long.
7. To enter/exit demo mode, press 1,2, and 3 simultaneously. This will disable welding and flash LEDs.
•
