7.1.1 Notes on which F codes change automatically
4‐Wire Gun Interfaces
Action
Result
F31 ‐ Drop TIme
F2 ‐ Plunge
Short Circuit
On‐Time
F44 ‐ Preset Bank
F30 ‐ Short
Cycle Enable
weld
max
weld
min
Other Notes
F30
Short Cycle
Mode = ON
7ms
20ms
2 (Short Cycle
Values)
‐
100ms
5ms
Limits Stud Expert studs, Limits
presets to 100ms max weld time.
F30
Short Cycle
Mode = OFF
12ms
20ms
1 (Drawn Arc
Metric Values)
‐
1000ms
100ms
Limits Stud Expert studs, Limits
presets to 100ms min weld time.
F12
Sud Feed
Enable = ON
‐
‐
‐
ON
‐
‐
2-Wire Gun Interfaces
Action
Result
F31 ‐ Drop TIme
F2 ‐ Plunge
Short Circuit
On‐Time
F44 ‐ Preset Bank
F30 ‐ Short
Cycle Enable
weld
max
weld
min
Other Notes
F30
Short Cycle
Mode = ON
35ms
20ms
2 (Short Cycle
Values)
‐
100ms
5ms
Limits Stud Expert studs, Limits
presets to 100ms max weld time.
F30
Short Cycle
Mode = OFF
35ms
100ms
0 (Drawn Arc
English Values)
‐
1000ms
100ms
Limits Stud Expert studs, Limits
presets to 100ms min weld time.
F12
Sud Feed
Enable = ON
‐
‐
‐
ON
‐
‐
For firmware version 1.05 only.
