Nera WorldCommunicator
GETTING STARTED
MOUNTING FIXED ANTENNA
Mounting
Fixed dish mounted
on mast.
Vertical adjustment bolts
(90 degree range)
Pole bracket
U-bolt
Horizontal adjustment
nuts
RF transceiver
Coax connector
Pole (option)
Max dia 120 mm
Note! The antenna should be mounted with the cooling fins on the
RF transceiver pointing upwards to ensure efficient cooling.
