1.5 Installing the MAX 410/420/430 Unit
Proceed with installation as follows:
1. Install the unit in a well-ventilated area. If it is to be placed on a surface rather than in a rack,
be sure that all four rubber feet are in place to allow for proper air circulation. Do not place
objects in excess of 20 pounds on top of the unit.
Please refer to the Net2Phone MAX 410/420/430 Hardware Installation Guide and observe
the safety precautions listed.
2. Connect an analog telephone to any one of the FXS ports. (MAX-420)
NOTE: For MAX 410, initial LAN configuration is done via a PC connected to the MAX through its
serial port, using the HyperTerminal terminal-emulator application (or equivalent), which is
included with all Microsoft™ operating systems. This procedure is explained in Section 2.1.2.1,
Connecting to the MAX 410/420/430 Using HyperTerminal.
3. Connect the RJ-45 LAN port to a hub or switch.
4. Connect your FXS and/or FXO ports to your PBX as per the illustrations in Figures 3, 4, and 5,
below.
Net2Phone MAX 410/420/430 User Guide Section 1.5 – Installing the MAX 410/420/430 Unit
