Max 410/420/430
15
2.1.2 Connecting to the Max 410 through a Serial
Cable
This section explains how to connect to the Max and
obtain its DHCP IP address. The remaining
configuration tasks can then be completed more
easily via the Max Web Manager.
NOTE: For the Max 410 units,
LAN settings can only be
configured using this method.
2.1.2.1 Using the HyperTerminal Emulation
Program
For this procedure you will need a standard
serial cable (D-sub 9-pin, male-to-female,
straight-through connection) as shown in Figure
6, and a PC running the HyperTerminal terminal-
emulator program (or an equivalent), which is
included with Microsoft operating systems. It is
usually found in the Programs menu, under
Accessories.
1. With the power to the Max 410 turned
OFF, connect the cable from the unit’s
serial port to one of the PC’s serial ports.
Figure 6
To Next Page
