Hardware Setup
10
AC1200 WiFi Router JR6100
The WiFi and WPS buttons toggle the WiFi and WPS functions on and off.
WiFi On/Off button. Pressing and holding this button for two seconds turns the 2.4 GHz
and 5 GHz wireless radios on or of
f. If the WiFi LED is lit, the wireless radios are on. If this
LED is off, the wireless radios are turned off and you cannot connect wirelessly to the
router.
WPS button.
Y
ou can use this button to use WPS to add a wireless device or computer
to your wireless network. The WiFi LED blinks blue when the router is trying to add the
wireless device or computer. The LED stays solid blue when wireless security is enabled
in the router.
Rear Panel
The rear panel has the connections and buttons shown in the following figure.
USB Ethernet Internet
Power On/Off
Power connector
port
LAN ports 1–4
Reset
buttonport
Figure 3. Router rear panel
Pressing the Reset button restores the factory settings. See Factory Settings on page 121.
