NETGEAR AC1200 JR6100

Supplemental Information
122
AC1200 WiFi Router JR6100
Technical Specifications
Wireless Wireless communication Enabled
SSID name See router label
Security WPA2-PSK (AES)
Broadcast SSID Enabled
Transmission speed Auto
Maximum wireless signal rate derived from IEEE
Standard 802.1
1 specifications. Actual throughput can
vary. Network conditions and environmental factors,
including volume of network traffic, building materials and
construction, and network overhead, lower actual data
throughput rate.
Country/region United States in the US; otherwise, varies by region
RF channel Auto
Operating mode Up to 300 Mbps at 2.4 GHz, Up to 867 Mbps at 5 GHz
Table 4. JR6100 Router specifications
Feature Description
Data and routing protocols TCP/IP, RIP-1, RIP-2, DHCP, PPPoE, PPTP, L2TP, Dynamic DNS, UPnP, and
SMBA
Power adapter • China: 220V, 50 Hz, input
• Europe: 230V, 50 Hz, input
• North America: 120V, 60 Hz, input
• UK, Australia: 240V, 50 Hz, input
• All regions (output): 12 VDC @ 1.5A, output
Dimensions Dimensions: 180 x 170 x 60 mm (7.08 x 6.69 x 2.36 in.)
Weight Weight: 322 g (0.71 lb)
Operating temperature 0° to 40°C (32º to 104ºF)
Operating humidity 90% maximum relative humidity, noncondensing
Electromagnetic emissions China SRRC and CCC
Russia EAC
LAN 10BASE-T or 100BASE-Tx, RJ-45
WAN 10BASE-T or 100BASE-Tx, RJ-45
Table 3. Factory default settings (continued)
Feature Default behavior
