NETGEAR AC1200 JR6100 User Manual

Hardware Setup
9
AC1200 WiFi Router JR6100
Front and Side Panels
The router front and side panels have the status LEDs and buttons shown in the following
figure.
LEDs
WiFi On/Off button
WPS button
Figure 2. Router front and side view
Table 1. Front panel LED descriptions
LED Description
Power
• Solid amber. The router is starting.
• Blinking amber. The firmware is upgrading, or the Reset button was pressed.
• Solid green. The router
is ready.
• Blinking green. The firmware
is corrupted. Visit www.netgear.com/support.
• Off. Power is not supplied to the router.
Internet
• Solid green. The Internet connection is ready.
• Solid amber. The modem has detected the Ethernet cable connection.
• Off
. No Ethernet cable is connected to the modem.
WiFi
• Solid blue. The wireless radio is operating in either 2.4 GHz or 5 GHz mode.
• Blinking blue. A wireless computer or device is using WPS to join the network.
• Off
. The wireless radios are off for both 2.4 GHz and 5 GHz.
USB
• Solid blue. The router has accepted the USB device. The USB device is ready to be used.
• Blinking blue. A USB device is plugged in and is trying to connect.
• Off
. No USB device is connected, or someone clicked the Safely Remove Hardware button,
and it is now safe to remove the attached USB device.

NETGEAR AC1200 JR6100 Specifications

General

USB Port	1 x USB 2.0
Parental Controls	Yes
Guest Network	Yes
Wi-Fi Technology	802.11ac
Wi-Fi Performance	AC1200 (300 Mbps + 867 Mbps)
Wi-Fi Band	Dual-band (2.4 GHz & 5 GHz)
Key Features	ReadySHARE USB
Security	WPA/WPA2-PSK
