Administration
77
AC1200 WiFi Router JR6100
• IP Address. The IP address used by the Internet (WAN) port of the router. If no address
is shown or the address is 0.0.0.0, the router cannot connect to the Internet.
• Connection. This shows if the router is using a fixed IP address on the WAN. If the value
is DHCP Client, the router obtains an IP address dynamically from the ISP.
• IP Subnet Mask
. The IP subnet mask used by the Internet (W
AN) port of the router.
• Domain Name Server. The Domain Name Server addresses used by the router.
A
Domain Name Server translates human-language URLs such as www.netgear.com into
IP addresses.
Show Statistics Button
To view statistics:
1. Select ADVANCED Home
or select Administration > Router Status.
2. In the Internet Port pane, click the Show Statistics button.
The following information displays:
• System Up Time
. The time elapsed since the router was last restarted.
• Port. The statistics for the WAN (Internet) and LAN (Ethernet) ports. For each port, the
screen displays:
- Status
. The link status of the port.
- TxPkts
. The number of packets transmitted on this port since reset or manual clear
.
- RxPkts. The number of packets received on this port since reset or manual clear
.
- Collisions. The number of collisions on this port since reset or manual clear
.
- Tx B/s. The current transmission (outbound) bandwidth used on the W
AN and LAN
ports.
- Rx B/s. The current reception (inbound) bandwidth used on the W
AN and LAN ports.
- Up Time.
The time elapsed since this port acquired the link.
- Poll Interval. The interval at which the statistics are updated in this screen.
3. To change the polling frequency, enter a time in seconds in the Poll Interval field and click
the Set Interval
button.
4. To stop the polling entirely, click the Stop button.
