Reference Manual for the ADSL Firewall Router DG834
Virtual Private Networking (Advanced Feature) 7-19
v2.0, September 2005
1. To launch this function, click on the Windows Start button, then select Programs, then
NETGEAR ProSafe VPN Client, then Log Viewer.
2. The Log Viewer screen for a successful connection is shown below:
3. The Connection Monitor screen for this connection is shown below:
In this example you can see the following:
• The DG834 has a public IP WAN address of 22.23.24.25.
• The DG834 has a LAN IP address of 192.168.3.1.
• The VPN client PC has a dynamically assigned address of 192.168.2.2.
Figure 7-18
Note: Use the active VPN tunnel information and pings to determine whether a failed
connection is due to the VPN tunnel or some reason outside the VPN tunnel.
Figure 7-19
