Reference Manual for the ADSL Firewall Router DG834
7-6 Virtual Private Networking (Advanced Feature)
v2.0, September 2005
• “Step 2: Configuring the NETGEAR ProSafe VPN Client on the Remote PC” on page 7-11
configures the NETGEAR ProSafe VPN Client endpoint.
Step 1: Configuring the Client-to-Gateway VPN Tunnel on the
DG834
The worksheet below identifies the parameters used in the following procedure. A blank
worksheet is at “Planning a VPN” on page 7-3.
Figure 7-3
Note: This section uses the VPN Wizard to set up the VPN tunnel using the VPNC
default parameters listed in Table 7-2 on page 7-4. If you have special requirements
not covered by these VPNC-recommended parameters, refer to “How to Set Up
VPN Tunnels in Special Circumstances” on page 7-35 to set up the VPN tunnel.
192.168.3.1
VPN Tunnel
DG834
22.23.24.25
PC
(Running NETGEAR
ProSafe VPN Client)
PCs
0.0.0.0
