Reference Manual for the ADSL Firewall Router DG834
Virtual Private Networking (Advanced Feature) 7-7
v2.0, September 2005
Follow this procedure to configure a client-to-gateway VPN tunnel using the VPN Wizard.
Table 7-1. VPN Tunnel Configuration Worksheet
Connection Name: RoadWarrior
Pre-Shared Key: 12345678
Secure Association -- Main Mode or Manual Keys: Main
Perfect Forward Secrecy -- Enabled or Disabled: Disabled
NETBIOS -- Enabled or Disabled: Enabled
Encryption Protocol -- DES or 3DES: 3DES
Authentication Protocol -- MD5 or SHA-1: SHA-1
Diffie-Hellman (DH) Group -- Group 1 or Group 2: Group 2
Key Life in seconds: 28800
(8 hours)
IKE Life Time in seconds: 3600 (1 hour)
VPN Endpoint Local IPSec ID LAN IP Address Subnet Mask
FQDN or Gateway IP
(WAN IP Address)
Client toDG834 — — Dynamic
DG834 toClient 192.168.3.1 255.255.255.0 22.23.24.25
