NETGEAR DG834

Reference Manual for the ADSL Firewall Router DG834
7-8 Virtual Private Networking (Advanced Feature)
v2.0, September 2005
1. Log in to the DG834 at its LAN address of http://192.168.0.1 with its default user name of
admin and password of password. Click the VPN Wizard link in the main menu to display
this screen. Click Next to proceed.
2. Fill in the Connection Name and the pre-shared key, select the type of target end point, and
click Next to proceed.
Note: The Connection Name is arbitrary and not relevant to how the configuration functions.
Figure 7-4
Figure 7-5
Enter t
h
e new
C
onnect
i
on Name:
(e.g., RoadWarrior)
Enter the pre-shared key:
(e.g., 12345678)
Select the radio button:
A remote VPN client (single PC)
