NETGEAR DG834

Reference Manual for the ADSL Firewall Router DG834
7-2 Virtual Private Networking (Advanced Feature)
v2.0, September 2005
Client-to-Gateway VPN Tunnels
Client-to-Gateway VPN Tunnels provide secure access from a remote PC, such as a telecommuter
connecting to an office network (see Figure 7-1).
A VPN client access allows a remote PC to connect to your network from any location on the
Internet. In this case, the remote PC is one tunnel endpoint, running the VPN client software. The
DG834 ADSL router on your network is the other tunnel endpoint. See “How to Set Up a Client-
to-Gateway VPN Configuration” on page 7-5 to set up this configuration.
Gateway-to-Gateway VPN Tunnels
• Gateway-to-Gateway VPN Tunnels provide secure access between networks, such as a branch
or home office and a main office (see Figure 7-2).
Figure 7-1
Figure 7-2
VPN Tunnel
DG834
PC
(Running NETGEAR
ProSafe VPN Client)
PCs
A
B
VPN Tunnel
DG834 VPN Firewall
DG834 VPN Firewall
PCs
PCs
