NETGEAR DG834

Reference Manual for the ADSL Firewall Router DG834
5-8 Managing Your Network
v2.0, September 2005
An alternate view of the Connection Status screen is shown in Figure 5-6 below:
Clicking the Renew button updates the status information.
This screen shows the following statistics:
Figure 5-6
Table 5-1. Connection Status Fields for PPPoA
Field Description
Connection Time The time elapsed since the last connection to the Internet via the ADSL port.
Connecting to
Sender
The connection status.
Negotiation ON or OFF
Authentication ON or OFF
IP Address The IP Address assigned to the WAN port by the ADSL Internet Service Provider.
Network Mask The Network Mask assigned to the WAN port by the ADSL Internet Service Provider.
