NETGEAR FVS124G User Manual

IPsec PFS: The setting must match the Perfect Forward Secrecy (PFS) setting in VPN Tracker (Advanced > Phase 2 >
Perfect Forward Secrecy (PFS)). Turning on PFS provides additional security.
IPsec PFS Key Group: The PFS key group must match the PFS Diffie-Hellman (DH) group in VPN Tracker (Advanced >
Phase 2 > Perfect Forward Secrecy (PFS)).
Traffic Selector
The Traffic Selection settings determine the endpoints of the VPN
tunnel.
‣
The local (=NETGEAR) side of the tunnel should be configured to
be a subnet matching the NETGEAR’s LAN
(192.168.13.0/255.255.255.0 is the NETGEAR’s LAN in our
example)
‣
The remote part should be set to “Any”.
AH Configuration
Enable Authentication: VPN Tracker uses Encapsulating Security
Payload (ESP) with authentication. Using Authentication Header
(AH) is not necessary and not supported. It should be turned off.
31
Advanced Users If you are not setting the remote part of the Traffic Selection to “Any” (for example, because you
have different VPN policies all used by clients connecting from dynamic IP addresses), it must match
exactly what is configured in VPN Tracker as the Local Address (or Local Network, if using a
Network to Network connection). Range type addresses are not supported in VPN Tracker.

NETGEAR FVS124G Specifications

Power

power requirements	12V DC, 1.2A

System Memory

processor	200 MHz 32-bit RISC
memory	4MB Flash, 16MB DRAM

Ports & Interfaces

LAN ports	Four (4) 10/100/1000 Mbps auto-sensing, AutoUplink RJ-45 ports
WAN ports	Two (2) 10/100Mbps Ethernet RJ-45 ports

Weight and Dimensions

dimensions	7.45 x 4.85 x 1.26 in. (18.92 x 12.31 x 3.19 cm)
weight	1.37 lbs. (0.62 kg)
