NETGEAR GC110 Hardware Installation Guide

Figure 4. Sample PoE business use case
ConnectionLine Color
Internet router or gatewayPurple
PoE devices such as Insight managed (or other) WiFi access points, Arlo (or
other) security cameras, and VoIP phones
Blue
Network devices such as a desktop computerBlack
Connect PoE equipment for surveillance and security
The following figure shows an example of how you can connect PoE and non-PoE
equipment to the switch for surveillance and security purposes.
In a small office or home office network, the blue network icon represents a router that
is connected to an Internet modem. In such a setup, you must connect one port on the
switch to a LAN port on the router.
Hardware Installation Guide20Applications
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports

NETGEAR GC110 Specifications

General

Switch type	Managed
Quality of Service (QoS) support	Yes
Console port	RJ-45
Power connector	DC-in jack
SFP module slots quantity	2
Installed SFP modules quantity	-
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Product color	Gray
10G support	No
MAC address table	- entries
