NETGEAR GS724T User Manual

Ethernet Audio Video
12
GS716T and GS724T Gigabit Smart Switches
To reload the page, click Refresh. To clear the statistics for one or more ports, select the check
box next to the interface or interfaces, and click Clear. To clear the statistics for all interfaces,
select the check box in the heading row, and click Clear Counters.
MSRP Reservation Parameters
Use the MSRP Reservation Parameters page to view information about the talker, listener,
and intermediate device status for the devices involved in each MSRP stream flowing
through the switch.
To display the MSRP Reservation Parameters page, click the Switching tab, then click MRP
> Advanced > MSRP Reservation Parameters.
Bad Header Displays the number of MSRP frames with bad header which were
received on the interface.
Bad Format Displays the number of MSRP frames with bad PDUs body format which
were received on the interface.
Frames Transmitted Displays the number of MSRP frames which were transmitted on the
interface.
Transmission Failures Displays the number of MSRP frames that an interface attempted to
transmit but failed.
Failed Registration Counter Shows the number of MSRP frames that failed to register on a device or
particular interface.
Table 1-2.
Field Description

NETGEAR GS724T Specifications

General

MAC address table	8000 entries
Jumbo frames support	Yes
Packet buffer memory	0.5 MB
Maximum data transfer rate	1 Gbit/s
Dimensions (WxDxH)	43 x 440 x 260 mm
Connectivity technology	Wired
Non-operating relative humidity (non-condensing)	0 - 95 %
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Mean time between failures (MTBF)	59524 h
Power consumption (typical)	40 W
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
SFP/SFP+ slots quantity	2
Basic switching RJ-45 Ethernet ports quantity	24
DHCP features	DHCP client
Switch type	Managed
Stackable	No

Weight and Dimensions

Weight	3200 g
