NETGEAR GS724T User Manual

Ethernet Audio Video
14
GS716T and GS724T Gigabit Smart Switches
Qav Parameters
Use the Qav Parameters page to configure and view the per-port IEEE 802.1Qav settings.
The IEEE 802.1Qav standard supports time-sensitive traffic streams by pacing all switch
traffic, including legacy asynchronous Ethernet traffic, through queuing and forwarding. When
a Talker declares a stream, it identifies whether the stream is Class A or Class B and
specifies the stream’s bandwidth requirements. Class A traffic has a higher transmission
priority than Class B traffic.
On the Qav Parameters page, you can view and configure selected bandwidth allocations for
Class A and Class B traffic. To display the Qav Statistics page click the Switching tab, then
click MRP > Advanced > Qav Parameters.
To configure the Qav parameters:
1. Select the check box next to the port to configure. You can select multiple ports to apply
the same settings to the selected interfaces. Select the check box in the heading row to
apply the same settings to all interfaces.
2. Configure the Class A MSRP delta bandwidth.
Failure Bridge MAC Identifies the MAC address of the switch where the failure occurred.
Stream Age The time, in seconds, since the stream destination address was added
to the Dynamic Reservations Entries table. A value of zero indicates
the destination address has not been added to the table.
Table 1-3.
Field Description

NETGEAR GS724T Specifications

General

MAC address table	8000 entries
Jumbo frames support	Yes
Packet buffer memory	0.5 MB
Maximum data transfer rate	1 Gbit/s
Dimensions (WxDxH)	43 x 440 x 260 mm
Connectivity technology	Wired
Non-operating relative humidity (non-condensing)	0 - 95 %
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Mean time between failures (MTBF)	59524 h
Power consumption (typical)	40 W
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
SFP/SFP+ slots quantity	2
Basic switching RJ-45 Ethernet ports quantity	24
DHCP features	DHCP client
Switch type	Managed
Stackable	No

Weight and Dimensions

Weight	3200 g
