GS700TS Smart Switch Software Administration Manual
4-25 Configuring Switching Settings
v1.0, June 2009
• Voice VLAN Aging Time – Enter the Voice VLAN aging time. The Voice VLAN aging
time sets the maximum inactivity time for a Voice VLAN port member after its MAC
Address is aged out. If the time since the last MAC Address with telephony MAC Address
was aged out exceeds the Voice VLAN aging time, the port is dropped from the Voice
VLAN. The default time is one day. The field format is Day, Hour, Minute. The Voice
VLAN aging time starts after the MAC Address is aged out from the Dynamic MAC
Address table. The MAC Address dynamic aging default time is 300 sec. For more
information on defining MAC address age out time, see “Dynamic Addresses”.
2. Select the device VoiceVLAN Status in the provided field.
3. If you selected Enable in the VoiceVLAN Status field, select the VoiceVLAN ID, Class of
Service, Remark CoS and enter the Voice VLAN Aging Time in the provided fields.
4. Click APPLY to update the device.
Port Setting
The Voice VLAN Port Setting screen allows network managers to add ports or LAGs to the Voice
VLAN.
To add ports or LAGs to the Voice VLAN:
1. Click Switching > Voice VLAN > Advanced > Port Setting. The Voice VLAN Port Setting
screen opens:
Figure 4-18
