GS700TS Smart Switch Software Administration Manual
Managing Security 6-25
v1.0, June 2009
2. Select the interfaces to which the ACLs are bound.
3. Select the ACL Name from the list in the provided field.
4. Select the interfaces to bind to the selected ACL Name by one of the following methods.
a. Click on the Unit’s or LAG’s gold bar to display the associated interfaces, and then select
the interfaces to bind by clicking on the boxes below the interfaces.
or
b. Click on the Unit’s or LAG’s quick box to select all the associated interfaces.
5. Click APPLY to update the device.
IPv4 ACL
The IPv4 ACL screen allows an IPv4 Based ACL to be defined.
To view or rename IPv4 Based ACLs:
1. Click Security > ACL > IPv4 ACL. The IPv4 ACL screen displays:
The IPv4 ACL screen contains the following fields:
IPv4 ACL
• Current number of ACL – Displays the current number of user-defined ACLs.
IPv4 ACL Table
• Name – Enter the user-defined IP based ACL name.
Figure 6-15
