GS700TS Smart Switch Software Administration Manual
4-53 Configuring Switching Settings
v1.0, June 2009
To delete all addresses from the Basic Address Table:
1. Click Switching > Address Table > Basic > Address Table. The Basic Address Table screen
displays.
2. Click CLEAR ALL to delete all entries in the address table.
Advanced
The Address Table Advanced menu contains the following options:
• “Static Addresses”
• “Dynamic Addresses”
• “Address Table”
Static Addresses
The Static Addresses screen contains a list of static MAC addresses. Static Addresses are added
and removed from the Static Addresses screen. To prevent static MAC addresses from being
deleted when the device is reset, ensure the port attached to the MAC address is locked.
To configure the Static MAC Address table:
1. Click Switching > Address Table > Advanced > Static Addresses. The Static Addresses
screen displays:
The Static Addresses screen contains the following fields:
• VLAN ID – Select the VLAN ID number to which the entry refers.
• MAC Address – Enter the MAC address to which the entry refers.
Figure 4-33
