GS700TS Smart Switch Software Administration Manual
3-57 Managing System Settings
v1.0, June 2009
The LLDP Statistics screen contains the following fields:
• Last Update – Indicates the last time the LLDP statistics were updated. The date and time
are displayed inthe following format, day-month-year hour:minute:second.
• Total Inserts – Indicates the total number of new entries since the last time the table was
last updated.
• Total Deletes – Indicates the total number of deleted entries since the table was last
updated.
• Total Drops – Indicates the total number of entries that could not be added to the table
due to lack of resources. These entries are dropped.
• Total Age-outs – Indicates the total amount of entries that were aged out since the table
was last updated.
• Interface – Indicates the stacking member for which the LLDP statistics are displayed.
• Tx Frames Total – Indicates the total amount of LLDP packets transmitted on the port.
• Rx Frames – Indicates the total amount of LLDP packets received on the port, including:
–Total – Indicates the total amount of valid LLDP packets received on the port.
– Discarded – Indicates the total amount of LLDP packets that were discarded on the
port.
– Errors – Indicates the total amount of LLDP packets that were errors on the port.
• Rx TLVs – Indicates the total amount of Type Length Value received on the port,
including:
Figure 3-29
