3. If you did not select the Remember me check box when you logged in previously, enter the modem
password in the Sign In field.
See the modem label for the default password.
4. Click the Sign In button.
The full Dashboard page displays.
In the connection graph, the broadband icon and the information below it display the following:
• Signal strength. Five bars in the broadband icon indicate the strongest signal. One bar indicates
the weakest signal.
• Service provider. The name of the mobile broadband service provider (or operator).
• Type of service. The type of service is indicated by icons that are described in the following table.
Different service providers can use different icons.The following figure shows an example of 4G
service. The following table shows the types of mobile broadband services.
• Connection state.The Internet connection state (Internet Connected or Internet Disconnected).
• Roaming state. If the modem is roaming, a roaming icon and notification might display.
Table 3.Types of mobile broadband service
Type of Mobile Broadband ServiceIcon
4GLong Term Evolution (LTE)4G
3GDual Carrier HSPA Plus
HSPA Plus
H+
HSPA
HSUPA
HSDPA
H
UMTS3G
2GEDGE
GPRS
2G
Model LB2120-100NAS does not support 2G.Note
Manage the Modem and Monitor Usage and the Network
67
LTE Modem Model LB2120
