NETGEAR M5300 Series - Bandwidth, Environment, and Model-Specific Technical Data

Technical Specifications
27
NETGEAR Managed Stackable Switch M5300 Series
Bandwidth • 136 Gbps (M5300-28G3/M5300-28G/M5300-28GF3/M5300-28G-POE+)
• 184 Gbps (M5300-52G3/M5300-52G/M5300-52G-POE+)
Dimensions (W x D x H) 440 x 391 x 43 mm (17.3 x 15.4 x 1.7 in.)
Environment Operating:
- Temperature: 32° to 122°F (0° to 50°C)
- Humidity: 90% maximum relative humidity, noncondensing
- Altitude: 10,000 ft (3,000 m) maximum
Non-Operating:
- Temperature: – 4° to 158°F (–20° to 70°C)
- Humidity: 95% maximum relative humidity, noncondensing
- Altitude: 10,000 ft (3,000 m) maximum
Electromagnetic
emissions and immunity
CE mark, commercial, FCC Part 15 Class A, VCCI Class A, Class A EN 55022
(CISPR 22) Class A, Class A C-Tick, EN 50082-1, EN 55024
Safety CE mark, commercial, CSA certified (CSA 22.2 #950), UL listed (UL 1950)/cUL
IEC950/EN60950
Table 5. Technical specifications - model specific
Feature M5300-28G-POE+
M5300-52G-POE+
M5300-28G M5300-52G
M5300-28G3
M5300-52G3
M5300-28GF3
Layer 3 services
• VLAN routing
• Port routing
• RFC2328 OSPF v2 (license needed)
• RFC2740 OSPF for IPv6 (license needed)
• RFC2453 RIP v2 (license needed)
• RFC1112 IGMP v1 (license needed)
• RFC2236 IGMP v2 (license needed)
• RFC3376 IGMP v3 (license needed)
• RFC4601 PIM-SM (license needed)
• RFC3973 PIM-DM (license needed)
• RFC2710 MLD (license needed)
• VLAN routing
• Port routing
• RFC2328 OSPF version 2
• RFC2740 OSPF for IPv6
• RFC2453 RIP Version 2
• RFC1112 IGMP version 1
• RFC2236 IGMP version 2
• RFC3376 IGMP version 3
• RFC4601 PIM-SM
• RFC3973 PIM-DM
• RFC2710 MLD
Heat dissipation
(Btu/hr)
M5300-28G-PoE+ 1829
M5300-52G-PoE+: 1896
M5300-28G: 186
M5300-52G3: 268
M5300-28G3: 186
M5300-52G3: 268
M5300-52GF3: 274
Acoustic noise (dB)
(ANSI-S10.12)
MM5300-28G-POE+: 44.8
M5300-28G: 37.3
M5300-52G-POE+: 43.2
M5300-52G: 34.9
M5300-28G3: 37.3
M5300-28GF3: 35.6
M5300-52G3: 34.9
Table 4. M5300 Series technical specifications (continued)
