Get Dynamically from ISP. Your ISP uses DHCP to assign your IP address. Your
ISP automatically assigns these addresses.
• Use Static IP Address. Enter the IP address, IP subnet mask, and the gateway IP
address that your ISP assigned. The gateway is the ISP router to which your router
connects.
13. Select a Domain Name Server (DNS) Address radio button:
•
Get Automatically from ISP. Your ISP uses DHCP to assign your DNS servers.
Your ISP automatically assigns this address.
•
Use These DNS Servers. If you know that your ISP requires specific servers, select
this option. Enter the IP address of your ISP’s primary DNS server. If a secondary
DNS server address is available, enter it also.
14. Select a Router MAC Address radio button:
•
Use Default Address. Use the default MAC address.
• Use Computer MAC Address. The router captures and uses the MAC address
of the computer that you are now using. You must use the one computer that the
ISP allows.
• Use This MAC Address. Enter the MAC address that you want to use.
15. Click the Apply button.
Your settings are saved.
16. Click the Test button to test your Internet connection.
If the NETGEAR website does not display within one minute, see You Cannot Access
the Internet on page 223.
Specify IPv6 Internet Connections
You can set up an IPv6 Internet connection if the router does not detect it automatically.
To set up an IPv6 Internet connection:
1. Launch a web browser from a computer or mobile device that is connected to the
router network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the router admin user name and password.
The user name is admin. The password is the one that you specified the first time
that you logged in. The user name and password are case-sensitive.
The Dashboard displays.
User Manual30Specify Your Internet Settings
Nighthawk Pro Gaming Router Model XR1000

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR Nighthawk Pro XR1000 and is the answer not in the manual?

NETGEAR Nighthawk Pro XR1000 Specifications

General IconGeneral
WiFi TechnologyWiFi 6 (802.11ax)
Processor1.5GHz triple-core processor
Antenna4 external antennas
USB Ports1 x USB 3.0 port
RAM512MB
Flash Memory256MB
MU-MIMOYes
QoSDynamic QoS
WiFi SpeedAX5400 (5.4 Gbps)
Ethernet Ports4 LAN @ 1G Mbps
Frequency BandDual-Band (2.4GHz + 5GHz)
SecurityWPA3, VPN support
