NETGEAR PS101 User Manual

NetGear Print Server Manual
106
Protocol than ASCII, but ASCII communication is more reliable. The default is ASCII.
Logical Port Tab
Logical printers (Logical Ports) can be used under Linux or Unix. The Print Server supports 3 Logical
Ports. This screen allows configuration of Logical Ports.
Logical Port Tab Window
Logical Port Tab Fields
Field Description
Current
Selected
Logical Port
Selects the logical port to be configured. Eight logical ports are available for print servers with two printer
ports; three logical ports are available for one printer port print servers.
Physical Port Selects which physical printer port the logical port is mapped into. Converts LF to LF+CRAdd a carriage
return (CR) every time the line feed (LF) character code is received by the print server when any print data
is sent to this logical port.

NETGEAR PS101 Specifications

General

Brand	NETGEAR
Model	PS101
Category	Print Server
Language	English
