NetGear Print Server Manual
117
VCCI Class B ITE
Safety Agency Approvals, Power Adapter
Meets requirements of:
CE mark, commercial
UL listed (UL 1950)
CSA certified (CSA 22.2 #950)
TUV licensed (EN 60 950)
T-Mark
PS110/PS113 2/3-Port Print Server Specifications
Network Protocol and Standards Compatibility
IEEE 802.3u, 100BASE-TX, Fast Ethernet
IEEE 802.3i 10BASE-T CSMA/CD
NetBEUI, IPX/SPX, AppleTalk, and TCP/IP protocols
Data Rate
100 Mbps with 4B/5B encoding and MLT-3 physical interface
10 Mbps differential Manchester encoded
Interface
10BASE-T/100BASE-TX network port (RJ-45)
2 or 3 Bi-Directional parallel printer ports
Power Specifications for the Power Adapter
Input voltage: 100 to 240 V AC, 50 to 60 Hz, according to the power adapter
Localized plug: For North America, Japan, UK, Europe, and Australia
Output voltage: 12 V DC at 1.2A
Power Specifications for the Print Server
Power consumption: 7 W maximum
Input voltage: 12 V DC at 1.2 Amps, maximum
Physical Specifications
PS110
Width: 7.4 in. (18.9 cm)
Height: 1.2 in. (3.0 cm)
Depth: 4.8 in. (12.2 cm)
Weight: 1.61 lb (0.73 kg)
PS113
Width: 9.3 in. (23.6 cm)
Height: 1.0 in. (2.6 cm)
Depth: 4.0 in. (10.1 cm)
Weight: 1.61 lb (0.73 kg)
