NETGEAR R6200 User Manual

Genie Basic Settings
27
Dual Band 11ac WiFi Router R6200
Share Name. If only one device is connected, the default share name is USB_Storage.
You can click the name shown, or you can type it in the address field of your web browser.
If Not Shared is shown, the default share has been deleted, and no other share for the
root folder exists. Click the link to change this setting.
Read/Write Access. Shows the permissions and access controls on the network folder:
All – no password (the default) allows all users to access the network folder
. The user
name (account name) for All – no password is guest. The password for admin is the
same one that you use to log in to the router. By default, it is password.
Folder Name. Full path of the network folder
.
Volume Name. V
olume name from the storage device (either USB drive or HDD).
Total/Free Space. Shows the current utilization of the storage device.
• Edit. Click the Edit button to edit the
Available Network Folders settings.
• Safely Remove a USB Device. Click to safely remove the USB device attached to your
router.
2. Y
ou can click Refresh to update this screen.
Basic Wireless Settings
The Wireless Settings screen lets you view or configure the wireless network setup.
The R6200 WiFi Router comes with preset security. This means that the Wi-Fi network name
(SSID), network key (password), and security option (encryption protocol) are preset in the
factory
. You can find the preset SSID and password on the bottom of the unit.
Note: The preset SSID and password are uniquely generated for every
device to protect and maximize your wireless security.
 To view or change basic wireless settings:
NETGEAR recommends that you do not change your preset security settings. If you change
your preset security settings, make a note of the new settings and store it in a safe place
where you can easily find it.
If you use a wireless computer to change the wireless network name (SSID) or other wireless
security settings, you are disconnected when you click Apply. To avoid this problem, use a
computer with a wired connection to access the router.

NETGEAR R6200 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Bandwidth	2.4 GHz
Rack mounting	No
Ethernet LAN (RJ-45) ports	5
Web-based management	-
Security algorithms	WPA, WPA2-PSK, WPS
Flash memory	16 MB
Certification	RoHS, WEEE, CEC
Internal memory	128 MB
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	77 mm
Width	205 mm
Height	255 mm
Weight	654 g
