Hardware Setup
9
Dual Band 11ac WiFi Router R6200
• Away from electrical devices that are potential sources of interference. Equipment that
might cause interference includes ceiling fans, home security systems, microwaves, PCs,
the base of a cordless phone, or a 2.4-GHz cordless phone.
• A
way from any large metal surfaces, such as a solid metal door or aluminum studs. Large
expanses of other materials such as glass, insulated walls, fish tanks, mirrors, brick, and
concrete can also af
fect your wireless signal.
When you use multiple access points, it is better if adjacent access points use different radio
frequency channels to reduce interference. The recommended channel spacing between
adjacent access points is 4 channels (for example, use Channels 1 and 5, or 6 and 10).
Hardware Features
Before you cable your router, take a moment to become familiar with the front, side, and back
panels and the label. Pay particular attention to the LEDs on the front panel.
Front and Side Panel
The router front panel has the status LEDs and icons shown in the following figure.
LEDs
WiFi On/Off button
WPS button
Figure 2. Router front and side view
