NETGEAR RP114 User Manual

Reference Guide for the Model RP114 Web Safe Router
Using the Manager Interface for Advanced System Maintenance 9-5
Syslog
Syslog can be configured in Menu 24.3.2 - System Maintenance - UNIX Syslog. Menu 24.3.2
configures the router to send UNIX system logs to another machine.
You must configure the parameters to activate syslog (Table 9-4).
To configure the router for logging with the syslogd program on a local host:
1.
Go to Menu 24.3.2 - System Maintenance - UNIX Syslog.
2.
Set Active to Yes.
3.
In the Syslog IP Address field, enter the IP address of the syslogd host PC.
4.
Select a number for Log Facility.
You can choose any facility number, but the syslogd program must be set to the same number.
5.
Select the type of activity that you would like to log.
You can enable the router to send the following types of syslog messages:
• Call detail record (CDR)
• Packet trigger
Table 9-4. System Maintenance - UNIX Syslog Fields
Field Command Description
Active Press the space bar to toggle between
yes and no.
The syslog option is turned on or off.
Syslog IP Address Enter the address in dotted-decimal
notation such as a.b.c.d where a, b, c,
and d are numbers between 0 and 255.
This field is the IP address location to
send your syslog.
Log Facility Press the space bar to toggle between
on and off.
Seven different local options can be
selected. The log facility allows the
message to be logged to different files in
the server. Refer to your UNIX manual
for more detail.
Types
CDR
Packet triggered
Filter log
PPP log
For each type, press the space bar to
toggle between yes and no.
Enable logging for:
Call detail record (CDR)
Packet trigger
Filter event (match or not match)
PPP event

NETGEAR RP114 Specifications

General

Dimensions (WxDxH)	159 x 102 x 32 mm
Connectivity technology	Wired
Supports ISDN connection	Yes
Product color	Blue
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	2750 g
