NETGEAR RP114 User Manual

Reference Guide for the Model RP114 Web Safe Router
Using the Manager Interface for Initial Router Configuration 7-11
Manager Password Setup
For security, you should change the Manager password from the default value of 1234.
To change the Manager password:
1.
Select option 23, System Password, from the main menu.
Menu 23 - System Password opens (Figure 7-5).
Figure 7-5. Menu 23 - System Password
RIP Version This field determines the format and broadcasting method of any RIP
(Routing Information Protocol) transmissions by the router. The following
RIP options are supported by the Model RP114 router:
• RIP-1—The router sends RIP-1 messages only.
• RIP-2B—The router sends RIP-2 messages in broadcast format.
• RIP-2M—The router sends RIP-2 messages in multicast format.
For most applications, the recommended version is RIP-1.
Multicast Some streaming media applications (e.g. Cisco IP/TV, RealPlayer) now
support IP Multicast. To enable Multicast routing, select either IGMP-v1
or IGMP-v2.
Table 7-5. Menu 3.2 - TCP/IP and DHCP Setup Fields (continued)
Field Description
Menu 23 - System Password
Old Password= ?
New Password= ?
Retype to confirm= ?
Enter here to CONFIRM or ESC to CANCEL:

NETGEAR RP114 Specifications

General

Dimensions (WxDxH)	159 x 102 x 32 mm
Connectivity technology	Wired
Supports ISDN connection	Yes
Product color	Blue
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	2750 g
