NETGEAR RP114 User Manual

Reference Guide for the Model RP114 Web Safe Router
B-10 Network and Routing Basics
IP Configuration by DHCP
When an IP-based local area network is installed, each PC must be configured with an IP address.
If the PCs need to access the Internet, they should also be configured with a gateway address and
one or more DNS server addresses. As an alternative to manual configuration, there is a method by
which each PC on the network can automatically obtain this configuration information. A device
on the network may act as a Dynamic Host Configuration Protocol (DHCP) server. The DHCP
server stores a list or pool of IP addresses, along with other information (such as gateway and DNS
addresses) that it may assign to the other devices on the network. The Model RP114 router has the
capacity to act as a DHCP server.
The Model RP114 router also functions as a DHCP client when connecting to the ISP. The router
can automatically obtain an IP address, subnet mask, DNS server addresses, and a gateway address
if the ISP provides this information by DHCP.
Ethernet Cabling
Although Ethernet networks originally used thick or thin coaxial cable, most installations currently
use unshielded twisted pair (UTP) cabling. The UTP cable contains eight conductors, arranged in
four twisted pairs, and terminated with an RJ45 type connector. A normal "straight-through" UTP
Ethernet cable follows the EIA568B standard wiring and pinout as described in Table B-3.
Table B-3. UTP Ethernet cable wiring, straight-through
Pin Wire color Signal
1 Orange/White Transmit (Tx) +
2 Orange Transmit (Tx) -
3 Green/White Receive (Rx) +
4Blue
5 Blue/White
6 Green Receive (Rx) -
7 Brown/White
8 Brown

NETGEAR RP114 Specifications

General

Dimensions (WxDxH)	159 x 102 x 32 mm
Connectivity technology	Wired
Supports ISDN connection	Yes
Product color	Blue
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	2750 g
