NETGEAR WGX102 User Manual

Reference Manual for the 54 Mbps Wall-Plugged Wireless Range Extender WGX102
Preparing Your Network C-19
September 2004 202-10042-01
• The default gateway is 192.168.0.101
4. Type
exit.
Configuring the Macintosh for TCP/IP Networking
Beginning with Macintosh Operating System 7, TCP/IP is already installed on the Macintosh. On
each networked Macintosh, you will need to configure TCP/IP to use DHCP.
MacOS 8.6 or 9.x
1. From the Apple menu, select Control Panels, then TCP/IP.
The TCP/IP Control Panel opens:
2. From the “Connect via” box, select your Macintosh’s Ethernet interface.
3. From the “Configure” box, select Using DHCP Server.
You can leave the DHCP Client ID box empty.
4. Close the TCP/IP Control Panel.
5. Repeat this for each Macintosh on your network.

NETGEAR WGX102 Specifications

Weight and Dimensions

dimensions	3 x 8.6 x 6.5 in, 75 x 220 x166 mm
weight	2.0 lb
