Reference Manual for the 54 Mbps Wall-Plugged Wireless Range Extender WGX102
7-6 Content Filtering in Router Mode
September 2004 202-10042-01
Viewing Logs of Web Access or Attempted Web Access
The log is a detailed record of what Web sites you have accessed or attempted to access. Up to 128
entries are stored in the log. Log entries only appear when keyword blocking is enabled, and no log
entries are made for the Trusted User. An example is shown below:
Figure 7-5: Logs menu
Log entries are described in Table 7-1
Table 7-1. Log entry descriptions
Field Description
Number The index number of the content filter log entries. Up to 128 entries are
available, numbered from 0 to 127. The log keeps a record of the latest
128 entries.
Date and Time The date and time the log entry was recorded.
Source IP The IP address of the initiating device for this log entry.
Action This field displays whether the access was blocked or allowed.
Web site The name or IP address of the Web site or newsgroup visited or
attempted to access.
